AD8226 ON DIP adapter

The AD8226 is a LOW POWER wide supply range (2.2V to 36V) instrumentation amplifier that requires only one external resistor to set any gain between 1 and 1000 Bandwidth 1.5MHz Wide supply 2.2 V to 36 V Current consumption 350uA Can use this in many apps to replace operational amplifier 741 or tl081 tl071 and others.

Simple LOW POWER Ambient Light Sensor Circuit

The AD8226 is designed to work with a variety of signal voltages. A wide input range and rail-to-rail output allow the signal to make full use of the supply rails. Because the input range also includes the ability to go below the negative supply, small signals near ground can be amplified without requiring dual supplies. The AD8226 operates on supplies ranging from ±1.35 V to ±18 V for dual supplies and 2.2 V to 36 V for single supply.

The robust AD8226 inputs are designed to connect to real-world sensors. In addition to its wide operating range, the AD8226 can handle voltages beyond the rails. For example, with a ±5 V supply, the part is guaranteed to withstand ±35 V at the input with no damage. Minimum as well as maximum input bias currents are specified to facilitate open wire detection.

The AD8226 is perfect for multichannel, space-constrained industrial applications. Unlike other low cost, low power instrumentation amplifiers, the AD8226 is designed with a minimum gain of 1 and can easily handle ±10 V signals. With its MSOP package and 125°C temperature rating, the AD8226 thrives in tightly packed, zero airflow designs.

• Gain set with 1 external resistor
• Gain range: 1 to 1000
• Input voltage goes below ground
• Inputs protected beyond supplies
• Very wide power supply range
• Single supply: 2.2 V to 36 V
• Dual supplies: ±1.35 V to ±18 V
• Bandwidth (G = 1): 1.5 MHz
• CMRR (G = 1): 90 dB minimum for BR models
• Input noise: 22 nV/√Hz
• Typical supply current: 350 μA
• Specified temperature: −40°C to +125°C

Applications

• Low Power Sensor
• Industrial process controls
• Bridge amplifiers
• Medical instrumentation
• Portable data acquisition
• Multichannel systems

Please check out my other usefull products in my store. New products added every weeks. My Tindie Products
