Interactive PIR Motion sensor

Name: Interactive PIR Motion sensor
SKU: 26227
Price: 20.00 USD
Availability: InStock

Interactive motion detection with dual PIR elements and light intensity sensor.

Designed by sbs.solutions in Latvia











Buy with confidence.

Our Tindie Guarantee protects your purchase from fraud. Learn More

Interactive motion detection with dual PIR elements and light intensity sensor.

What is it? Two PIR and one light sensor with microcontroller and interactive leds. It is a combination of two sensors - PIR and light intensity with separate discrete outputs for PIR and Light accor…

What is it?

Two PIR and one light sensor with microcontroller and interactive leds. It is a combination of two sensors - PIR and light intensity with separate discrete outputs for PIR and Light accordingly. Two PIR sensors can be combined with AND / OR logic. PIR output can be combined with adjustable light intensity sensor. Can be used as stand alone motion/light activated driver or in combination with many DIY boards - Arduino, ESP8266, ESP32 etc.

What makes it special?

It has very attractive led indication. Separate led for every PIR sensor and one for status. This makes much easier to install and test. No need for complex analog to digital conversion on host MCU as light sensor with adjustable threshold level pot can be combined with PIR sensor.

Specification:

Max detection distance: 8m Supply voltage: 3.3 - 45V DC Current consumption: 1.7mA (Leds off) Output signal (PIR and Light): 3.3V, max 10mA, active=high Time delay adjustment: 2s - 5min Light threshold adjustment: 0-10 (relative light units)
