Product Features

• Choose from 5 input modes: XInput, Switch, PS4,PS3 and Keyboard.

• Overclocked polling rate with input latency of less than 1ms in all modes. Multiple SOCD cleaning modes - Up priority (aka non-stick), Neutral, and Back input priority. D-pad + LS/RS mode switchable.

• TURBO and TURBO LED speed selectable

• Multiple LED configurations, per-button RGB LED support.
• PWM player indicator LED support (XInput).
• Supports 128x64 monochrome 12C OLED display forintuitive viewing of key value information.
• Support customized boot LOGO.

Product Detail

RGB lighting effect is turned off:

• Press and hold SELECT+START+B atthe same time to reduce the light until it is turned off.

• OLED screen can visually view key value information.

Product Parameters

Product Description

• Working voltage: 5V

• Link method: USB Type-C

• Product size: 210mm * 120mm * 11mm

• Supported Platforms : pc /ps3/ps4/switch/ Android/Steam

• Product Specifications:1Mini Keyboard,1Data Cable Type-C,1Keycap Puller,6 anti slip pads

Mode switch

When plugging in the joystick, pressing and holding the following buttons to turn on the device will switch modes, and the switching mode will be saved even if the power is turned off.

A- Nintendo Switch: Applicable to Nintendo Switch

B- PC/XInput: suitable for PC computer or PC 360

X- PS3/Dinput: Suitable for PS3/PC host mode

Y-PS4: PS4 game mode suitable for PS4 console/PS5 console

RT-HID KB: HID computer keyboard mode

D-Pad mode

To switch to D-Pad mode, press the following button when turning on the computer:

SELECT + START + DOWN - Normal D-Pad mode

SELECT+ START+LEFT-Left analog stick mode

SELECT + START + RIGHT-right analog stick mode

Swap the up and down arrow keys

When the controller is working:

Press and hold at the same time: HOME+START+RINGHT- swap the key positions of the up and down arrow keys

SOCD mode

Switching to SOCD mode can achieve some special operations such as thick coverage. Press the following buttons when turning on the computer:

HOME + START + DOWN-return to center (U+D=N, L+R=N)

HOME + START+UP-direction priority (U+D=U, L+R=N)

HOME +START +LEFT-last input takes precedence
