the ecological sensor kit Module is a range -mechanically-compatible System on Modules (SoMs) containing processor, peripherals, set of sensors and supporting power circuitry. These modules allow a designer to leverage the ecological sensor kit hardware and software stack in their own custom systems and form factors. In addition these modules have extra IO interfaces over and above, opening up more options for the designer.

Design your own Indoor air quality sensor kit and service and implement it into:

• household electronic devices;
• furniture and interior items;
• creating electronic devices with original design under the own brand name.

Сonnect Eco sensor kit with various devices for transmitting and using data from sensors.

Manual in attached documents!

Consider the following connection options:

• Personal Computer
• Raspberry PI
• Android device

Features:

Hardware

• ESP 32 based
• 3G, NB-IoT, LoRa, BLE, Wi-Fi as communications methods
• Set of important sensors
• Low cost
• Low power
• High availability
• High reliability

Peripherals

• 4x GPIO
• 1x I2C
• 1x SPI

Software:

• ThingSpeak - The IoT Platform with MATLAB Analytics
• ThingsBoard open IoT Platform
• Applications (Android 7.0 and up) for settings of the access wi-fi point service and the frequency of sending data

Base version:

Package includes

Block with GSM slot and following sensors:

• CO2 (Telaire T6703)

• TVOC (BOSCH BME 680)

• Temperature (BOSCH BME680)

• Pressure (BOSCH BME680)

• Humidity (BOSCH BME680)

• Light (TI OPT3001)

• Noise (AD DMP401)

Block for battery

Durable plastic tool box case

Options available

Add to base version following features

E-ink screen

Screen Features:

• No backlight, keeps displaying last content for a long time even when power down;
• Ultra low power consumption, basically power is only required for refreshing;
• SPI interface, for connecting with controller boards like Raspberry Pi/Arduino/Nucleo, etc.;
• Onboard voltage translator, compatible with 3.3V/5V MCUs;
• Nano/Arduino/STM32);
• Specifications;
• Operating voltage: 3.3V~5V
• Interface: 3-wire SPI, 4-wire SPI
• Outline dimension: 103.0mm × 78.5mm
• Display size: 84.8mm × 63.6mm
• Dot pitch: 0.212 × 0.212
• Resolution: 400 × 300
• Display color: black, white
• Grey level: 2
• Full refresh time: 4s
• Refresh power: 26.4mW(typ.)
• Standby power: <0.017mW
• Viewing angle: >170°

Formaldehyde sensor

HCHO (Winsen ZE08-CH2O)

Do not compatible with Ozone sensor

You can choose version with Formaldehyde, or version with Ozone

Ozone sensor

O3(Winsen ZE25-O3)

Do not compatible with Formaldehyde sensor.

You can choose version with Formaldehyde, or version with Ozone.

Dust sensor

• PM1.0 (Plantover PMS7003/G7)

• PM2.5 (Plantover PMS7003/G7)

• PM5.0 (Plantover PMS7003/G7)

• PM10 (Plantover PMS7003/G7)
