PCB and FR4 front panel (only) for a buffered multiple synth module. This module is in LMNC's Kosmo format (20 cm high) and is 5 cm wide.

This module features a low parts count, single PCB design. There are two inputs each of which is buffered to four outputs; the second input is normalled to the first, so the module can be used as a single 1 to 8 multiple or a dual 1 to 4.

High (1M) input impedance and in-the-loop output resistors mean negligible change to 1 V/octave signals.

The user needs to source parts and assemble them. (Photo of my own assembled module for illustrative purposes only.) Easy through-hole construction.

Be sure to see the Github repository (linked below) for BOM, build notes, and other information.
