Bare PCB for 3D Startrek Enterprise

Name: Bare PCB for 3D Startrek Enterprise
SKU: 4997
Price: 24.99 USD
Availability: InStock
Rating: 3.75 (2 reviews)

(2 Reviews)

LED flashing 3D space ship model

Designed by Bobricius in Slovakia

Buy with confidence.

Our Tindie Guarantee protects your purchase from fraud. Learn More

Have you seen my other products? What you think? Your idea will be included in the next version! Fell free to write me. Anyway, your purchase or contribution via www.patreon.com/bobricius will help.

LED flashing 3D space ship model

READ PLEASE !!! You can order> "Animated PCB" with soldered and programmed Attiny85 IT IS NO KIT, NO OTHER COMPONENTS INCLUDED (LEDs) ONLY ATTINY85, NOTHING MORE SOLDERED Attiny85 only with firmware…

READ PLEASE !!!

You can order>

"Animated PCB" with soldered and programmed Attiny85 IT IS NO KIT, NO OTHER COMPONENTS INCLUDED (LEDs) ONLY ATTINY85, NOTHING MORE SOLDERED
Attiny85 only with firmware - no PCB !!! you can order 10 cheap boards directly from DirtyPCBS this variant is only Attiny85 in bag, nothing more !!!!
New Easy solder bare PCB only no mcu required, without LEDs Galery with lights and Some pictures assembled board IT IS NO KIT, JUST BARE PCB, NO COMPONENTS INCLUDED, NOTHING SOLDERED

NOTE:

I have new EASY solder model, this model is simplified for soldering etc. with 3528 LED's, no animation, no programming. Special if you do not know how to program attiny, or are you scared with working with. You can use self flashing leds, it not synchronized but there is way .... Can be powered with micro USB or AAA batteries, not together if you connect USB remove battery !!!

Board is ready for sale but with small manufacturing bug 2 pads missing but you can solder LED to track..., check board page for DETAILS

Some details for MCU version:

10x10 cm of PCB board
Attiny85 to individual control 20 (some LEDSs are parallel ) LED with charlieplexing
about 40 LED total
AAA battery in stand for power
full 3D construction
it can not fly :-(

For more details go to project page ENTERPRISE

You can order more boards (10pcs pack) cheap direct from factory DirtyPCBS

do not forget select 10x10 boards and white color !!!

No country selected, please select your country to see shipping options.

Change Destination Country:

Review Breakdown

Average Ratings

Product: (4.00)

Documentation: (3.00)

Shipping: (4.50)

Communication: (3.50)

Saverio | April 20, 2021

Instruction ti setup

Please send me a clip/video in order to fix and set up the Enterprise to
tani.saverio@gmail.com
Thx

Dustin | Sept. 14, 2020

Love the kit

I bought the bare pcb animated kit with preinstalled chip. I really enjoyed building this kit and can stare at the animations for hours. I used the pastebin parts list pgvoorhees posted on the hackaday project page. https://pastebin.com/VPNC49LW Included everything but the pink LEDs. Also note, the bottom_LED_position.png is mirror imaged. So all the + indicators are backwards.
