TFT 320x240 Arduino NANO shield

Name: TFT 320x240 Arduino NANO shield
SKU: 17350
Price: 19.95 USD
Availability: InStock
Rating: 4.00 (1 reviews)

(1 Review)

TFT shield provides a convenient and fast interface for connecting to the Arduino NANO display 320x240, uSD card and camera (OV7670, etc).

Designed by ElecDev in Russia

This seller is taking a break. Sign up below to get an email when they're back!

$19.95

On A Break

Electronic devices for hobbyest and professionals. IoT, Home Automation, Smart Home.

TFT shield provides a convenient and fast interface for connecting to the Arduino NANO display 320x240, uSD card and camera (OV7670, etc).

What is it? The TFT Arduino NANO shield provides a convenient and fast interface for connecting to the Arduino NANO display 320x240, uSD card and camera. What makes it special? The board has several …

What is it?

The TFT Arduino NANO shield provides a convenient and fast interface for connecting to the Arduino NANO display 320x240, uSD card and camera.

What makes it special?

The board has several connectors:

Connector for connecting Arduino NANO.
Connector for connecting a TFT display 320x240 (displays of various diagonals 2.4", 2.8" and 3.2" can be used, as well as connecting the display both on one side of the board and on the back).
Connector for camera connection (it is possible to capture the image from the camera and display the live image from the camera on the display).
MicroSD slot for reading / writing large amounts of data: for example, you can store images in jpeg format or video file with the extension "rgb", which can then be viewed on the display.
Rx, Tx ports (for connecting the Bluetooth HC-05 module), analog inputs, GPIO, I2C.

The board is powered from a separate USB port or from contacts "+5V" and "GND".

A special library (for Arduino IDE) was written for working with fonts, graphics, touchscreen, cameras, images, etc.

Example projects link:

No country selected, please select your country to see shipping options.

Change Destination Country:

ElecDev Shipping Policy:

For international orders, as we have to go to the central post office, we usually send items only two times per week, so, your order can take 7 days to be shipped.

Review Breakdown

Average Ratings

Product: (5.00)

Documentation: (3.00)

Shipping: (4.00)

Communication: (4.00)

Donald | March 27, 2021

Co-processors combination yield easy capture and display

A microprocessor is great for many tasks, but image capture and display task it greatly. This 'shield' is actually a co-processor and performs image capture and display under the command of the microprocessor. The design is both conceptually and practically nice -- the result is a compact and quite usable unit. Along with a Nano or Nano clone, one of many 320x240 SPI TFT displays complete the unit. The shield has a separate USB power jack, but this is common for all high-power graphics displays. The designer has created a good Arduino library, and has posted tutorials. The documentation is good, but I would suggest some curation/summary of all of the available material. The designer has other similar modules based on the FT810, so it is likely that this shield uses such a circuit, but the library allows developers to avoid low-level interface code.
