27C322 27C160 27C800 27C400 TL866 Minipro EPROM Programmer adapter

What is it? Programming adapter for all versions of TL866 programmer. Supported EPROMS are 27C322, 27C160, 27C800 and 27C400. make sure to select "27C4096" device, disable "check ID" and adjust VPP …

What is it?

Programming adapter for all versions of TL866 programmer. Supported EPROMS are 27C322, 27C160, 27C800 and 27C400.

make sure to select "27C4096" device, disable "check ID" and adjust VPP voltage if needed (refer to the datasheet of a programmed device)
it is important to insert EPROM into the lowest possible position as shown in the picture -follow DIP switch manual and use the corresponding combination in binary format to access specific 512kB block of memory

27C400 is programmed in one cycle

27C800 is programmed in two cycles

27C160 is programmed in four cycles

27C322 is programmed in eight cycles (need to change position of DPDT switch from "others" to "27C322")

Supplied with high quality ZIF48 socket from 3M.
