The Micro Node is 17mm x 17mm wireless Arduino board (the Atmel ATMega328P) micro-controller + RFM69CW 915, 868 or 433 MHz radio
Designed by easySensors in ChinaSign up to get notified when this product is back in stock!
The Micro Node is a low cost wireless Arduino IDE compatible (the Atmel ATMega328P 8MHz) microcontroller with RFM 69 CW radio on board and a few other nice additions. Best suitable for Home Automat…
Read More…
Best suitable for Home Automation, IOT. Could be used as core board for radio controlling any DIY project.
Pin out:
| Arduino Pins | Description |
|---|---|
| A4, A5 | Available ARDUINO analog GPIO / DIGITAL GPIO |
| D10 | Connected to RFM69 CS |
| ANT | RFM69 antenna |
| Vcc | Unregulated power up to 6.5 Volts |
| Gnd | Ground |
Arduino IDE Settings
programming FTDI adapter connection
