Features:

Fanless Ultra-Quiet Design: This power supply series is engineered with a fanless architecture to achieve an ultra-quiet operation, making it ideal for environments where noise levels must be kept to a minimum. The compact design also ensures easy portability, allowing you to carry it effortlessly to different workspaces or testing environments.

High Precision and Low Ripple: Featuring high resolution settings of 10mV and 1mA, these power supplies provide extremely precise voltage and current control. The low ripple and noise characteristics ensure smooth and stable output, important for sensitive electronic testing and development.

Advanced Protection and Monitoring: The units come with over-voltage and over-current protection mechanisms to protect your equipment. Additionally, the output voltage and current curve monitoring feature enables real-time tracking, ensuring you can immediately detect and correct any discrepancies.

Versatile Programmability: Equipped with a list waveform editing function, the power supplies allow you to create and store up to 10 editable timing output groups. This is particularly useful for complex testing scenarios that require custom power sequences. The built-in storage can save up to 4 groups of data for quick recall and reuse.

User-Friendly Interface and Connectivity: A 2.8-inch TFT LCD display provides a clear and user-friendly interface for setting and monitoring parameters. With a USB communication interface that supports SCPI, you can easily integrate the power supply with automated test systems and control it via a computer, enhancing your workflow efficiency.

• USB communication interface, support SCPI

• Over voltage / over current protection -

Output voltage and current curve monitoring function

Specifications:

Model

SPS6051

SPS3081

Rated Output

(0℃-40℃)

Voltage

0 -60V

0 -30V

Current

0 - 5A

0 - 8A

Power

150W

120W

Load Regulation

Voltage

≤30mV

Current

≤20mA

Power Regulation

Voltage

≤30mV

Current

≤20mA

Setting Resolution

Voltage

10mV

Current

1mA

Readback Resolution

Voltage

10mV

Current

1mA

Seting Accuracy

(25℃±5℃)

Voltage

≤0.05% ± 20mV

≤0.1% ± 20mV

Current

≤0.05% ± 20mA

≤0.2% ± 20mA

Readback Accuracy

(25℃±5℃)

Voltage

≤0.05% ±20mV

≤0.1% ±20mV

Current

≤0.05% ±20mA

≤0.2% ± 20mA

Ripple/Noise(*)

Voltage

≤30mVp-p

≤30mVp-p

Voltage

≤4mVrms

≤5mVrms

Current

≤10mAp-p

≤30mAp-p

Output temperature coefficient

(0℃-40℃)

Voltage

100ppm/℃

Current

200ppm/℃

Readback temperature coefficient

Voltage

100ppm/℃

Current

200ppm/℃

Response Time(50%-100% rated load)

≤1.0ms

Storage

4 groups of data

Working Temperature

0-40℃

Display

2.8 inch color LCD display

Interface

USB Device

Dimension

82mm（W）× 142mm（H）×226mm（D）

Weight

Approx. 1.8 kg

Package Included:

1 x Power Supply (Model as your choice)

1 x Power Cord

1 x User Manual

1 x Fuse

1 x USB Cable
