Lot 25. A DC permanent magnet commutator motor DPM-25-H1-07T is designed for use as a power motor and for driving various mechanisms in short-term, intermittent, and continuous operation in industrial automation, telemechanics, and radio electronics equipment.

Specifications: OСТ 160.515.022-76.

Motor designation structure: • DPM-25-H1-07T • DPM – DC motor with permanent magnet excitation; • 25 – Frame size number; • H1 – Single output shaft end; • 07T – Motor type.

Technical characteristics of DPM-25-H1-07T motor: • Supply voltage, V: 27 • Rated power, W: 2.54 • Rotational speed, rpm: 4500 • Rated torque, mNm: 5.39 • Starting torque, mNm: 12.3 • Current consumption, A: 0.35 • Efficiency, %: 27 • Weight, kg: 0.12

Year of Manufacture: These motors were produced starting from 1976 based on the OST standard (OСТ 160.515.022-76).
