2pcs/lot USB-uart program download and communications test module USB-3.3V-5V power supply module
Install the USB download cable driver
After installation you can use to download later Note that the USB download cable share COM port
Average desktop is COM3 or COM4, notebook is COM4-COM5-COM6-CO…
After installation you can use to download later Note that the USB download cable share COM port
Average desktop is COM3 or COM4, notebook is COM4-COM5-COM6-COM7
Open the ISP download software,
(1) First select the type of MCU
(2) and then choose to download the HEX file
(3) select the corresponding COM slogan (the most important)
(4) Click to Download Download
(5) speaks five core ISP line with the target board butt
Notes:
(1) COM port must choose the correct
(2) in the download, the target board does not have the power at work, that is no electricity
(3) Note that the order of 5-pin ISP cable, the default sequence is as follows:
A ------------------------------------------------- ----
Blue-TXD
Purple-RXD
Gray-GND
White - Empty
Black-VCC
B -----------------------------------------------------
Green-TXD
Yellow-TXD
Orange-GND
Red - Empty
Gray-VCC
