OpenFFBoard SPI to BISS-C dual RS485 adapter

Name: OpenFFBoard SPI to BISS-C dual RS485 adapter
SKU: 29335
Price: 10.00 USD
Availability: InStock

Interface module for BISS-C encoders for the OpenFFBoard

Designed by Gigawipf in Germany

OpenFFBoard SPI to BISS-C dual RS485 adapter 1

OpenFFBoard SPI to BISS-C dual RS485 adapter 2

OpenFFBoard SPI to BISS-C dual RS485 adapter 3


Buy with confidence.

Our Tindie Guarantee protects your purchase from fraud. Learn More

Interface module for BISS-C encoders for the OpenFFBoard

This module allows the OpenFFBoard (seperate product) to use its SPI3 (EXT) header to communicate with common BISS-C encoders like the JKD-4-22PF-G05BL (used on Mige motors). The SUB-D 15 female conn…

This module allows the OpenFFBoard (seperate product) to use its SPI3 (EXT) header to communicate with common BISS-C encoders like the JKD-4-22PF-G05BL (used on Mige motors).

The SUB-D 15 female connector matches the pinout of Mige motors and some others directly.

The BISS-C encoder module can only be used with certain motor driver modes:
