DC 3-6V Magnet DC Motor Model J24018 for Studying Magnetic Line of Force

1.Introduction: This is a simple permanent magnet DC motor model to demonstrate the DC electric motor working principle. It can be taken apart and reassembled when powered with DC 3-6V voltage. Ro…

1.Introduction:

This is a simple permanent magnet DC motor model to demonstrate the DC electric motor working principle.
It can be taken apart and reassembled when powered with DC 3-6V voltage.
Rotate like a real electric motor ideal for school scientific projects or physics teaching.

2.Features:

Easy installation.
Rare accessories.
Experimental display.
Obvious effect.
Wide applicability.

3.Parameter:

Product name:Electric Motor model DIY Kit
Model:J24018
Working voltage:DC 3.0V-6.0V
Material:plastic + metal
Usage: Study magnetic lines of force
Magnet size:222020mm(0.860.790.79 inch)
Magnetic flux density:>=72mT
Operating Temperature:-20℃~70℃
Operating Humidity:5%-90%RH
Installed size:14910cm(5.513.543.94 inch)

4.Function:

To understand the main structure of the electric motor.
Verify the relationship between rotor rotation and current direction and magnetic lines.
Master the principle of motor operation.

5.Components List:

Items in the package: Finished product after installation:

6.Note:

DC electric motor experiment：input 3V - 6V DC through wires and terminals, the coil will rotating, and speed up when voltage step up.
To avoid short circuit, two electric brushes can't touch the commutator segment.
Its working voltage is DC 3.0V-6.0V. DC12V is not recommended.
