Features:

1. microwave sensors using planar antenna and receiving echo.
2. The switch is active sensors.
3. The sensors emit a high-frequency electromagnetic waves and receives their echo.
4. The sensors detect changes within echo.
5. The sensors detect tiny movement in detect range.
6. Send signal to MCU and execution instruction.
7. Signals are likely to be detected through the door, glass and thin walls.
8. It will get best probe result if person or object when moving toward the sensor.
9. This product is a strong anti-jamming capability, almost without wind, heat and other environmental factors foreign interference

Parameter:

1. Size: 33*32mm
2. Contol power: 3-7W
3. Input voltage: 10-28VDC
4. Output current: 240mA
5. Sensor angle: 360 degree
6. Delay: 20-50s
7. Sensor distance: 4-8meter

Usage notice:

1. It is better away from wall about 3-4 meter.against get sensor from another side of wall;
2. Open areas more responsive

Usage notice:

1. It is better away from wall about 3-4 meter.against get sensor from another side of wall;
2. Open areas more responsive
