Chamaeleon64 can use its color-changing iridophores to blend in, or to mesmerize you.

Designed by Evil Genius Labs LLC in United States of America

This seller is taking a break until Jan. 1, 2025. Sign up below to get an email when they're back!














$64.00

On A Break

Chamaeleon64 can use its color-changing iridophores to blend in, or to mesmerize you.

Chamaeleon64 can use its color-changing iridophores to blend in, or to mesmerize you. It consists of three different printed circuit boards (PCBs), stacked up and mounted to each other with M2 stando…

Chamaeleon64 can use its color-changing iridophores to blend in, or to mesmerize you.

It consists of three different printed circuit boards (PCBs), stacked up and mounted to each other with M2 standoffs and screws.

The top PCB has the Chamealeon design in exposed FR4 (fiberglass) on both sides that allows the light from the LEDs on the middle PCB to shine through. White silkscreen on matte black (or black silkscreen on white) soldermask provides all of the details of the design on both sides. Holes for M2 bolts/screws are included on all three PCBs.

The middle PCB has 64 WS2812C-2020 2mm square addressable RGB LEDs and eight decoupling capacitors already surface-mounted in the shape of the Chamaeleon design. They're arranged so that the head, body, legs, and tail can each easily be lit completely individually. The top and bottom of the LED PCB are large 5V and GND planes, although the LEDs need only 5mA per color channel each, 960mA total max for solid white, full brightness. Two separate three-pin headers are provided. One for 5V, Data In, and GND, and the other for 5V, Data Out, and GND. The Data Out pin can be used to connect to even more LEDs.

The bottom PCB has the Chamaeleon design in white silkscreen on both sides.

Options

Chamaeleon64 can be purchased as a kit with the three PCBs and M2 hardware for you to use your own controller, such as one of my LED controllers, a Pixelblaze by ElectroMage, etc.

The Fully Assembled option includes all three PCBs, already assembled with M2 hardware and pre-programmed Wemos D1 Mini ESP8266 controller.

The Fully Assembled option requires, but does not include, a USB Micro B cable and power source (USB port, AC power adapter, battery pack, etc).

Specifications

PCB Size: 3.39 x 3.39 x .063 inch (86 x 86 x 1.6 mm) each
Three 2 layer printed circuit boards
FR4 substrate
White silkscreen with black SMOBC (solder mask over bare copper) or
Black silkscreen with white SMOBC (solder mask over bare copper)
Lead-Free HASL (Hot Air Solder Leveling) Finish
Designed and assembled in the US by Evil Genius Labs
