Introduction

BEE LYNK ADAPT is a compact USB to serial adapter equipped with BEE (20pin 2.0mm) sockets. With integrated CP2104 IC, It can be used for programming or communicating with MCU applications. On the other hand, you may connect your PC to various wireless applications via the BEE LYNK compatible modules.

Application

• USB to Serial adapter for communicating with TTL/CMOS level Serial devices.
• A 5V power source for a breadboard MCU applications
• USB Adapter for BEE modules (for PC wireless function).

Features

• Reset button for BEE modules
• 3.3V and 5V compatible TTL line available via 4 pin header
• USB 2.0 protocol
• Selectable VCC of 3.3V or 3.7V for BEE modules.
• On-board MIC29302 high-current, high-accuracy, the low-dropout voltage regulator can handle up to 3A of load current.
• Compatible with XBee Series, GSM, WiFi, Bluetooth & GPS BEE LYNK modules.

Key Specifications

• Microprocessor-CP2104
• PCB size-6.3x3.4 cm
• Indicators-POWER, SLEEP, ASSOC, RX, TX LEDs
• Power supply input-5V DC
• Interface-Micro USB, 2.54mm pitch pin header
• Adapter socket-XBee compatible 2.0mm pitch female pin header
• Connectivity-USB
• Communication Protocol-UART
• ROHS-YES

Package Contents

1. BEE LYNK ADAPT Base Board x 1 Nos.
2. Jumper Wires (Female-Female) x 4 Nos.
3. Micro USB Data Cable x 1 Nos.
