4-Channel Opto-Coupler Card (OPTOFAST)

Name: 4-Channel Opto-Coupler Card (OPTOFAST)
SKU: 8830
Price: 6.00 USD
Availability: OutOfStock
Rating: 5.00 (1 reviews)

(1 Review)

Fast Four Channel Opto-coupler card

Designed by Land Boards, LLC in United States of America

This seller is taking a break until Jan. 10, 2025. Sign up below to get an email when they're back!

4-Channel Opto-Coupler Card (OPTOFAST) 1

4-Channel Opto-Coupler Card (OPTOFAST) 2

4-Channel Opto-Coupler Card (OPTOFAST) 3




$6.00

On A Break

Helping Makers Go Beyond Breadboards

Fast Four Channel Opto-coupler card

See our other Optocoupler cards OPTOFAST-2 - Speed improved 4 channel optocoupler card - Suggested replacement for this card OPTOSMALL - Four channel optocoupler card OPTOOUT8-I2C - Eight channel op…

See our other Optocoupler cards

OPTOFAST-2 - Speed improved 4 channel optocoupler card - Suggested replacement for this card
OPTOSMALL - Four channel optocoupler card
OPTOOUT8-I2C - Eight channel optocoupler card - I2C interface
OPTOUSB - Optically coupled USB to FTDI interface
OPTOFASTBI - Two Optos in Two Directions

What is it?

Opto-Isolator card
4-Channels
4N25 Optoisolators
Input /Output isolation
Transistor driver for Opto LED reduces required drive from 10 mA to under 500 uA
Input channels share their own common VCC/Ground
Output channels share their own common Vcc/Ground
8-pin header for input
8-pin header for output
Configuration Options (Speed enhanced, Bypass Input transistors, Remove Output collector resistors)
49x49mm
(4) 4-40 mounting holes

Why did you make it?

Our previous card, the OptoSmall, worked great but we thought we'd look into speeding it up. We found an Application Note which described how to speed up an opto-coupler and we built/tested the upgrade.

What makes it special?

Faster than the average card.
