Helping Makers Go Beyond Breadboards

Eurorack Prototyping card set

What is it? Eurorack Prototyping card set This is a set of 3 PCBs, you supply the parts to build what you want 6 HP wide (30mm) front panel 3U tall Three card set Board interconnect headers duplicat…

What is it?

Eurorack Prototyping card set
This is a set of 3 PCBs, you supply the parts to build what you want
6 HP wide (30mm) front panel
3U tall
Three card set
Board interconnect headers duplicated on headers
28mm wide controls and prototyping cards allow for mechanical variations
6 POTS
Marked as RV1-RV5
Series resistors on pot wiper
All 3 pot pins brought to top header
4 Jacks
Marked as J1-J4
Tip/sleeve brought to header near middle/bottom
Pots on top, jacks on bottom of card
Easier to adjust pots without bumping into cables in jacks
Pots more often accessed than jacks
Large prototyping area
58 nodes with 3 holes per node (29 per "side")
Holes are large enough to fit 2 or 3 leads into each hole (depending on lead sises)
+12V, -12V down board edges
5V/GND down center of card
Bussed connections horizontally
Front Panel with generic labels can be covered with White on Black P-Touch labels

Why did you make it?

I wanted to prototype various Eurorack designs without building custom cards. I built a noise generator, MOZZI with Arduino NANO, CV pots cards onto the card. If your design has 0-6 pots and 0-3 jacks and not too many individual nodes it will likely fit onto the card.

What makes it special?

I was able to build quite a few designs into the prototyping area.

Price Break

There is a price break for qty 3 card sets. If you order 3 cards, they ship as a panel that needs to be snapped apart. The cards separate easily from each other since they are V-scored. It's just a bit easier to ship them as panels.

Our other Eurorack cards
