Z80, 6502, 6809, FPGA Multicomp PCB (RETRO-EP4)

Name: Z80, 6502, 6809, FPGA Multicomp PCB (RETRO-EP4)
SKU: 18192
Price: 15.00 USD
Availability: InStock

Carrier board for WaveShare CoreEP4CE6

Designed by Land Boards, LLC in United States of America

This seller is taking a break until Jan. 10, 2025. Sign up below to get an email when they're back!

Z80, 6502, 6809, FPGA Multicomp PCB (RETRO-EP4) 1

Z80, 6502, 6809, FPGA Multicomp PCB (RETRO-EP4) 2

Z80, 6502, 6809, FPGA Multicomp PCB (RETRO-EP4) 3

Z80, 6502, 6809, FPGA Multicomp PCB (RETRO-EP4) 4

Z80, 6502, 6809, FPGA Multicomp PCB (RETRO-EP4) 5

Z80, 6502, 6809, FPGA Multicomp PCB (RETRO-EP4) 6

Z80, 6502, 6809, FPGA Multicomp PCB (RETRO-EP4) 7



$15.00

On A Break

Helping Makers Go Beyond Breadboards

Carrier board for WaveShare CoreEP4CE6

This is a PCB only no other parts. You will have to source the other parts to build this card. The parts are available on Mouser or Digikey. The SRAM is a fine pitch surface mount part. The FPGA card…

What is it?

A card which receives a WaveShare Altera EP4CE6 card and provides connections to VGA, PS/2, USB-Serial port, SD Card, 512 KB of SRAM.

Why did you make it?

I love Grant Searle's Multicomp project. It lets you create 6502, Z80, 6809 Retrocomputers of the late 1970s era. This card provides all of the connections needed.

Grant's original design used an EP2 but that's not compatible with the latest version Altera/Intel Quartus.This upgrades to the newer EP4CE6 FPGA. We've done the work of porting the Multicomp to this card.

Here's the features list:

6 bit video on VGA
PS/2 connector
512KB of SRAM for banked use in CP/M
Mount for inexpensive FTDI USB to serial converter
SD Card
DC power jack

What makes it special?

It really lets you play around with retro computing or designs of your own. It leaves plenty of extra I/O for your own expansion and designing.

No country selected, please select your country to see shipping options.

Change Destination Country:

Land Boards, LLC Shipping Policy:

We keep a small quantity of assembled/tested boards but we have material in-house to build/test additional boards. Domestic (USA) orders ship as soon as the cards is built/tested.

If your tracking code begins with "AHOY" (outside of North America), please use https://a1.asendiausa.com/tracking/ for tracking.

$15.00
