DC-DC LDO 5V (Pack of 3)

Name: DC-DC LDO 5V (Pack of 3)
SKU: 29232
Price: 5.98 USD
Availability: InStock
Rating: 4.75 (1 reviews)

(1 Review)

DC-DC LDO is a DC-DC Module with a TO-220 form factor. This is designed to replace existing Linear regulators in use, like LM7805, etc.

Designed by MAKERPALS in India

Buy with confidence.

Our Tindie Guarantee protects your purchase from fraud. Learn More

Christmas Winter Sale is live from 16th December to 28th December. Grab the last chance of getting 15% off this year.

DC-DC LDO is a DC-DC Module with a TO-220 form factor. This is designed to replace existing Linear regulators in use, like LM7805, etc.

READY TO SHIP IN 12 HOURS Update: Batch Dated 04.03.23 is RoHS Compliant. Update: Batch Dated 15.03.23 is RoHS Compliant, Comes with effective price tiers and Fast Shipping. What is it? DC-DC LDO i…

READY TO SHIP IN 12 HOURS

Update: Batch Dated 04.03.23 is RoHS Compliant.

Update: Batch Dated 15.03.23 is RoHS Compliant, Comes with effective price tiers and Fast Shipping.

What is it?

DC-DC LDO is a DC-DC Module with a TO-220 form factor. This is designed to replace existing Linear regulators in use, like LM7805, etc, and is pin-to-pin compatible. The main advantage of using this DC-DC is to reduce the heat generated in the Linear Regulator (LDO) and reduce the size of the design as now you will not need to put a separate heatsink on your board.

Pinout

Specifications

Uses Texas Instruments DC-DC Converter IC
Compact size: 16mm x 13mm
Input Voltage: up to 15V DC
Output Voltage: 5V
Peak Efficiency: >91%
Continuous Current: 1.2A for 5V
Peak Current: 3A
DC-DC operates at ~600Khz
Protections: O/P short circuit(hiccup)/Thermal
