LoRaP30Pro is a super-power 30W LoRa spread-spectrum serial network wireless transmission product developed by NiceRF. It uses advanced Lora™ spread spectrum modulation frequency hopping technology, integrates hardware and software anti-crash scheme and LBT anti-interference mechanism.

The software is an all-in-one design. It can be switched to different working modes quickly and easily through the PC interface provided by NiceRF according to the user requirement, including the usual point-to-point, point-to-multipoint transparent transmission. And the MESH algorithm designed for wireless independent research and development, the characteristics of automatic routing can form a network transmission without blind zone and distance limitation. Users can also enable data AES128 encryption to get a more secure data transmission.

The product is designed to be TTL/RS232/RS485 three-level and is widely used in wireless remote transmission control industries.

Note: The LoRa Pro series can be configured to be compatible with several previous Lora data transmission modules of our company.

Feature

• AES128 data encryption
• No blind zone and distance limitation
• LBT（Listen Before Talk）Features
• Diversified serial port parameters
• Operating voltage range: 12~ 30V
• Up to 40 communication channels in the same frequency band
• LORA modulation mode, MESH self-organizing network mode
• Built-in hardware reset protection circuit
• TTL/RS232/RS485 Level
• Sensitivity up to -139 dBm
• Maximum output power>30W（+45dBm）
• range of working temperature：-40 ~ +85 °C

Application

• Remote wireless
• remote control
• Industrial data collection
• Wireless data communication
