USB µISP

Name: USB µISP
SKU: 2917
Price: 19.97 USD
Availability: InStock
Rating: 4.79 (19 reviews)

(19 Reviews)

voltage-agile, USB connected AVR microcontroller programmer

Designed by Geppetto Electronics in United States of America


Buy with confidence.

Our Tindie Guarantee protects your purchase from fraud. Learn More

The store will be closed February 15th through May 15th.

voltage-agile, USB connected AVR microcontroller programmer

What is it? This item is a USB connected AVR programmer. It's compatible with AVRDUDE (use the "usbtiny" -c argument) and the Arduino IDE. It is a composite clone of the AdaFruit USB Tiny programmer …

What is it?

This item is a USB connected AVR programmer. It's compatible with AVRDUDE (use the "usbtiny" -c argument) and the Arduino IDE.

It is a composite clone of the AdaFruit USB Tiny programmer and the SparkFun Pocket AVR programmer.

Like the SparkFun Pocket AVR, it is SMD, which makes it small. It also has a PTC fuse to protect the USB host computer. But where the SparkFun device has a mini USB, I've gone with the more ubiquitous micro USB receptacle.

Like the AdaFruit Tiny USB programmer and the SparkFun programmer, this device has bus buffers which allow it to be able to program the target regardless of what voltage the target system uses, be it 3.3, 5 or anything else (within reason). SparkFun tried to improve the design by adding a pull-up resistor to insure that when the USB bus was disconnected that the bus buffers would be turned off, preventing the programmer from interfering with the target device. Unfortunately, SparkFun made an error which allows USB power to "leak" through the pull-up resistor they added. This design corrects that error with a blocking diode.

I've also added a 3.3 volt LDO so that target power can be switched between 3.3 volts, 5 volts, or no target power (meaning that the target is self-powered during programming).

There is also a current-limiting switch in the target power path, which protects both the host and the programmer from shorts and transients, making it safe to hot-plug the target.

This version is safe to use with 3.3 volt or 5 volt targets while supplying power, including hot-plugging the target. It comes complete with a 6" 6 wire .1" DIP ribbon cable for connecting to a standard 6 pin AVR ISP interface (micro-USB cable not included).

In addition, there's an extra pin on this programmer that outputs a 500 kHz square wave during programming. This "recovery clock" allows you to recover controllers that you have inadvertently fused for an external crystal that is not present. By connecting this pin up to the "XTAL2" pin (on most AVR models), and using "-B 250" with AVRDUDE, you can reset the fuses to the factory state to recover from incorrect fusing.

Why did you make it?

I've been using the SparkFun programmer for as long as I've been doing this, but the mini USB port and the target power "leak" always bothered me just a little. So I decided to give a try at my own design, and this is the result.

What makes it special?

It can work with 3.3 volt and 5 volt target systems safely supplying power to either, and can safely program at other voltages with the target self-powered, has a micro-USB connector, and a built-in recovery clock output pin.

Special note:

Do not use the Adafruit USB VID/PID without written permission from Adafruit Industries, LLC and Limor "Ladyada" Fried (support@adafruit.com). Permission is granted for 8pino.cc, Geppetto Electronics, littlewire, Ihsan Kehribar and Seeed Studio and Sparkfun by Adafruit Industries, LLC to use the Adafruit USB VID/PID for approved products. The USB µISP is one such approved product.

No country selected, please select your country to see shipping options.

Change Destination Country:

Geppetto Electronics Shipping Policy:

Due to VAT regulations, orders to the UK must now be a minimum of £135 or include recipient VAT number.

Orders to the EU should include recipient's VAT number, if available, to avoid delivery delays.

Other international customers: Import duties, taxes and all other fees are the recipient's responsibility. Returned shipments will be either retried at customer expense or refunded minus shipping charges.

Review Breakdown

Average Ratings

Product: (4.89)

Documentation: (4.53)

Shipping: (4.95)

Communication: (4.79)

Alexander | Dec. 6, 2023

Almost 9 years later and still going strong

I bought this device from Gepetto in February of 2015. Since then, it's been tossed into many random drawers, been through two apartment moves, and yet every time I've used it it's always *just worked* which says something about the design and designer!
Many moons ago when I was getting into microcontrollers, the AVR Dragon was the new hotness. You'd think the official programmer board from Atmel would have been resilient, but nope. It somehow died, as did my MkII ISP. Yet between this, my PicKit 3, and my MPLAB Snap, I've got all the bases covered with devices that actually last and don't just randomly die while sitting on the shelf between uses.
Thanks for making such a great little programmer!

Bernard | Oct. 11, 2020

Fast and easy to use

Too busy using the programmer to write a review!

Works well with most of the AVR family. I had been using an Arduino to program other AVR chips and while this worked, it wasn't as smooth as i would like. This works 100% of the time and is much faster and simpler to use.

Jason | June 1, 2020

OMG THE BEST

Bought this a while back and it has saved me countless times. Never ever would i replace it. Thank You!

Dave | Dec. 14, 2019

a fantastic little programmer

I've had several Atmel programmers over the years, including a (now dead) AVRisp mkII, and a (now dead) Pololu PGM03A. This one has withstood the test of time and many, many programmings. I used it with a pogo-adapter for programming literally hundreds of boards.

I really like the switchable power, a great convenience and saves me from having to make some kind of mezzanine jig for providing power to my boards during program+test.

Charlie | Oct. 15, 2017

Works well with avrdude, well-designed.

This programmer is tiny and works well, and in particular writes firmware faster than an AVR Dragon. LED tells you when it's working.
My one feature ask would be exposing at least the power/ground if not all 6 pins on a pass-through connector for goofier setups, like an external power supply to the device being programmed.

I did have one die (unrecoverable by waiting for polyfuse) under mysterious circumstances that may well have included me short-circuiting somewhere.

Chiche | Oct. 12, 2017

Good and handy tool for Arduino development.

Excellent product with good quality. Talked to designer and communication is great as well. highly recommended.

Eric | July 2, 2017

µISP is the best AVR programmer I've used

I just used this for first time, to copy flash and EEPROM from one Mega328P to another. Worked beautifully. Great prduct!

It's really helpful that it has a switch to select between 3.3V, 5V, or target power, and that it can supply 200mA of power to the target.

The last AVR programmer I used had an unshrouded 2x3 header. This one has a shrouded header, so the ribbon cable can't be plugged in wrong at the programmer end.

Timothy | April 10, 2017

This is the programmer I've been looking for

This design fills all the needs I presently have for AVR programming, and closes the loop on several deficiencies in the sparkful model. I'd buy it again in a heartbeat and would definitely recommend it. I can't think of a single thing I'd change!

Marc | Feb. 15, 2017

Super fast shipping to Canada

Very impressed with the speed of shipping - placed the order on Friday and got it in the mail Wednesday (3 business days) - to my address in Canada. Happy to see the cable was included. The unit itself is very small and does exactly what I need.

Vlad | Oct. 19, 2016

This is TINY

Very small and nicely made, includes cable. Shipping was 1 day to San Francisco. Thank you for everything!

Josh | Aug. 2, 2016

Excellent product and excellent seller!

I have a project that uses a custom ATmega328p-based board that typically runs at 2V, but can run at up 3.3V during programming. Unfortunately, I didn't have a 3.3V programmer while a deadline was very imminent. Nick Sayer was extremely prompt in shipping it to me, and the product itself works well. After a few initial test programs were running much slower than expected, I realized the system clock was running at 1MHz, and the Arduino code was expecting it to be running at 16MHz. I then proceeded to upload the standard Arduino bootloader, but I didn't actually check the fuse bits on the bootloader, and I ended up bricking the ATmega328p. However, the onboard recovery clock on the programmer saved the day! I soldered a small wire to it, and then carefully held it up against my QFN32 packaged ATmega328p with one hand, while I hit "enter" with the other hand on the keyboard to tell the terminal to execute the avrdude command that would set the fuses back to what I really needed them to be all along.

So far, I am very impressed with this product.

Peter | July 26, 2016

The USB uISP is the simplest ICSP ive ever used!

I love the USB uISP, it was by far the best documented, best designed, and easiest to use this far for me.

Dann | June 24, 2016

Very nicely designed, very compact, universal device.

Very nicely designed, very compact universal device. I'm using it as a "backup programmer" and "portable programmer" for development work.

Compared to the AVR-ISP-MK2, the USB mISP is noticeably slower in operation, but I feel that is a reasonable trade-off for the compact package with a micro USB connector. Very portable, and uses ubiquitous micro USB cables.

BTW, it arrived *very* quickly, almost like Amazon Prime! ;)

Thank you, Nick! :)

Jay | Feb. 18, 2016

Fine product.

The USB uISP programmer is a good product at a good price, and it was delivered quickly. And once I got it configured, it worked.

However, I had never seen or used an ISP programmer before, so for me it was a little difficult to find the necessary documentation and software. If the vendor would just include a little slip of paper with URL's of appropriate resources, it would be a perfect product.

Josh | Jan. 21, 2016

Great little programmer

This is a great little programmer compact & well built. It's a plus that there is also a case for it to keep things protected. I'm not a fan of the micro usb connector, but it seems solidly on the board.
A great feature, that I haven't tested yet, is the ability to solder on a header pin for a clock-recovery signal (to reset bad fuse settings, ie: external clock when there is none).
Easily allows you to switch from 3.3v to 5v
No problem with drivers on win8 x64. My new main isp programmer!

Daniel | April 15, 2015

Great AVR Programmer!

This programmer is small and has worked great without any problems so far. Much better than the SparkFun AVR Programmer, especially since it has a 6-pin header instead of a 10-pin header. I've been using this with a Tag-Connect TC2030-IDC-NL cable.

Paul | Jan. 9, 2015

Beautiful and tiny

Has enough power to program even with 100 ohm resistors connected to the data pins. Very high quality build. It's even smaller than it looks in the picture. Thanks.

Mike | Dec. 1, 2014

Excellent quality

I have not tried this product out yet but the quality of the design is excellent. This was on sale for such a great price that I grabbed one as a backup in case my regular one fails.

Winchell | Sept. 29, 2014

Does the job at the right price

The unit works as advertised for a nice price.
And while I happen to live geographically close to the seller, wow, it arrived in about 1.5 days!
Recommended
