Description

This Sony ECX33AF Micro OLED Display is a 0.6 cm (type 0.23) diagonal, 640 (RGB) × 400 dots active matrix color OLED panel module using single-crystal silicon transistors. This panel incorporates panel driver and logic driver, and realizes small size, light weight and high definition.

Specifications

• Display Type:OLED Display
• Display Size:0.23"
• Resolution:640*400
• Display Color:Full color
• Pin No:51P
• Brightness:800 cd/m2
• Interface Type:parallel RGB 24-bit, YCbCr 24-bit and YCbCr 16-bit input
• Driver Board:HDMI PORT
• Optics: Available
• Panel Size:15.6 x 13.6 x 0.2 (mm)
• Active Area:8.143x 6.146 (mm)
• Operation Temperature : -10℃~70℃
• Storage Temperature : -30℃~80℃

Features:

• Small-size, high-definition-type 0.23 nHD+ display dots 640 (RGB) × 400 = 0.77M dots
• High contrast
• Wide color reproduction range
• High-speed response
• Thin type and light weight
• Power-saving function
• Up/down and/or right/left inverse display function

• Orbit supportedApplications:

• ARVR product

• Digital camera camera electronic viewfinder
• Portable civilian equipment such as micro projectors, video glasses, head-to-use entertainment equipment, 3D display, game helmets, etc.
• Security monitoring, military use single-man helmet display, electronic scope, infrared night vision, thermal imaging, electronic telescopes, aircraft helmets, vision, life detection video devices,
• Medical and industrial use human and machine video engineering research, endoscope, portable B ultra-machine, vision correction equipment, enhanced glasses, a variety of portable inspection and testing equipment
• Aircraft model aerial photography, remote control aircraft parameters display system, remote control car video display terminal, etc.
• Minerals coal detection, metal mineral detection
