ESP32-C3 Air Quality Monitor PCB

Name: ESP32-C3 Air Quality Monitor PCB
SKU: 34873
Price: 8.00 USD
Availability: InStock

Air Monitoring PCB for PMS7003 sensor with xiao module ESP32-C3

Designed by PlantCare in United States of America


Buy with confidence.

Our Tindie Guarantee protects your purchase from fraud. Learn More

Air Monitoring PCB for PMS7003 sensor with xiao module ESP32-C3

Features:

Seeed Xiao SMD layout
Operating Voltage 5V DC
PMS7003 Sensor Pins
Additional breakout pins
Battery Breakout pins for certain modules

Compatible modules:

XIAO ESP32C3

PMS7003 Specifications:

Measurement range: 0.3~1.0；1.0~2.5；2.5~10 μm
Effective range: 0~500 μg/m³
Max. range: ≥1000 μg/m³
Resolution: 1 μg/m³
Power supply: 5V
Logic(UART) voltage: 3.3V
Operating current: up to 100mA
Standby current: ≤200 μA
Dimensions: 47.8 x 36.8 x 12 mm / 1.9" x 1.4" x 0.5"

Pinout

D0 = GPIO2 = PMS7003 RST
D1 = GPIO3 = PMS7003 RX
D2 = GPIO4 = PMS7003 TX
D4 = GPIO6 = PMS7003 SET

Kit Content:

1 x Air Monitoring PCB

Note: header pins and other items are only for reference!

No country selected, please select your country to see shipping options.

Change Destination Country:

PlantCare Shipping Policy:

Packages are picked up by carrier by 10AM daily. Late orders are shipped the next business day, holidays excluded.

Quantity	Price
1-9	$8.00
10-39	$6.00
40+	$5.49
