#### What is it? --> --> PORTUGAL PT developed

GET CONNECTED development KIT embedded ARM module plus 8x Zigbee mesh modules plus GSM/SMS/3.5G data modem & LoRaWAN "The Things Network" high power ultra long range and high building penetration city long range low frequency spread spectrum anti jamming radio 148MHz-174MHz. WiFi or other wireless radio bands optional add on.

Quick smart IoT development over advanced certified protocols and modules plus quick development on open source example nodejs and websockets. Full support community with a lot of tutorials and examples for all modules. NODE.js EVENT programming approved (tha best!! web server 6lines code easy handle uart 20lines code can command / monitor ZiBee mesh network from webpage) But can choose any language. All possible with this stuff.

SUPER connectivity over large mesh very secure intelligent network up to 65536 nodes or multiples. Remote instantly IO's control and data acquisition super easy. Trigger actions on any nodes using events from inputs , timer, counter etc. Easy read multiple analogs inputs from remote target node. Easy set Outputs on remote nodes.Easy auto node manipulate IO's on trigger, toggle etc. Self input external/internal trigger possible.And pin trigger loop. Auto network nodes join & setup plus network announcement similar to "Hey I'm here!" . Auto continuous channel configure Anti jamming capability. Ultra secure certified IEEE 802.15.4 AES256 mesh network with password option for join and remote commands. Can choose Trusted center node Remote upload or clone firmware.** Possible tables of binds.

Say yeahhh.

Certified, Ultra low power. ARM embedded linux state of ART mesh network full control. Easy broadcast data, remote IO configure, remote IO reading. Interruption or polling. PWM output. Pulse counter. increment/decrement trigger.

Example of auto remote trigger over mesh config. Internal ZibBee configuration only - Define input 7 on node FFAA trigger on rise with debounce. At event turn on remote pin on node AA23 RPC and turn on self pin 4 and 5 than send data to sink with all IO's data and go to deep sleep 10seconds. After wake up do announcement with all IO's battery voltage and analogs inputs and increment counter. Send tracking data each second to tracking remote monitor sink node and if counter reach threshold value do some action on remote node. - This is a crazy idea. But you can see that everything is possible with this configurations. Kind of if then statements language to trigger actions and explore play with registers and IO's and events.

Object tracking using all surrounding nodes intelligent tracking method.

This is a amazing development platform KIT for quick interaction with ZigBee mesh network. Full IO's controlled remotely instantly, data acquire, interruptions or IO's events for auto actions. Precise timer / counter trigger actions. Everything is possible with this stuff!!

Easy high level webpage code. Example nodejs plus websockets fly on ARM. Any code you like on powerful ARM embedded linux Italian engineer made AriaG25 plus amazing full of fuctions ZigBee modules from Telegesis UK company but now belongs to Silicon Labs.

Plus powerful shielded high quality LORA modules high power high wall penetration 147MHz to 174Mhz for long range inside buildings and inside city. Or open field or sea super long range.

And also high quality GSM / SMS / 3.5G 7.2MBps stream unlocked USB data module with SIM insert for any network worldwide. Open source linux drivers. Can use module internal antenna or external high gain antenna

Full modules support on official webpages. Many examples and engineered tutorials. Quick install linux on SD card and running. All steps explained on tutorials and examples.

#### Why did you make it?

I developed this system for any developer to enjoy the amazing capabilities of the ZigBee mesh network using state of art hardware modules , linux embedded ARM, PCB optimized design, plus wide network connectivity with ZigBee , 3.5G , GSM , SMS , Lora high performance and WiFi or others possible. Initially developed for smart agriculture field telemetry monitor , and events timed / triggered actions and WEB APP on top of that using nodejs.

#### What makes it special?

Is possible to quick develop any kind of app to have full control of ZigBee network and easy webpage data visualization. Plus many extra networks connections.

ZigBee modules easy AT commands by serial.

AT+JN --> join best network of pre defined one. Auto join possible defined on trigger , IO event , timed, etc

EASY commands similar

BCAST:data_here

UCAST:00FF00FF00FF,data_here or pre defined group cast.

Easy set IO's and remote registers. Set node output pin to one ATREMS:000D6F00000AAC93,37=1

Get register, data or IO state, analog etc from any node on tha network. ATREMS:000D6F00000AAC93,6F?

See AT COMMANDS official dictionary check documentation below tindie.com documentation download for a comprehensive examples to view easy examples AT commands never seen before. Many of configurations possible. You will be amazed with so many potential. Possible make modules autonomous on pin and events actions and IO's manipulation / internal/external trigger.

Full AT command dictionay official document click here

Check ARIA g25 ARM linux module click here Easy linux debian embedded official tutorial install on SD click here

BE AMAZED with nodejs installing and running server in few minuts! hello world from node.js ARM click here

ARM MCU official technical documentation click here

LOTS of examples and tutorials here for ARM module click here

ZigBee modules technical data sheet click here And the power amplifier ZigBee version click here

smart RPC remote procedure call ultra low power mesh network

PCB hardware details:

• Onboard supercapacitor for GSM / 3.5 radio data bursts energy backup.
• SD card Reader
• ETH secure Ethernet connection
• USB 2.0 port for 3.5G/GSM data sticker (worldwide networks bands compatible and unlocked). Possible connect USB hub for multiple USB and WiFi module or other Serial TTL etc.
• RTC battery. keep on time!
• USB board supply ultra stable and filtered for stable power supply and high reliability continuous running non stop.
• ZigBee ETRX357 connect to serial in 1 of ARM AriaG25 module. Use UART interrupt on UART1 to process data income from network. Node.js event programming do that great. listen at serial for string. Easy serial write nodejs. Read AT commands list dictionay to know all the strings to interface Zigbee module and ARM serial 1.

PROBABLY THA MOST ADVANCED IoT network telemetry development platform on tindie dot com

The funds from selling this KIT will be for new development already on progress for a new advanced intellingent mesh network of IO's over WiFi modules with WEB APP Windows, Linus MAC Android and iOS app. And if you buy this KIT you will receive the first new development KIT for a reduced value. This new development will be announced soon here on tindie dot com

Any questions or learning fell free to contact. If you need consulting or any kind of development feel free to contact.

Thanks for your time.

Vitor M Portugal PT

ARE YOU READY? ?YDAER UOY ERA
