External Watchdog Timer for IoT on MCs

Name: External Watchdog Timer for IoT on MCs
SKU: 23757
Price: 4.90 USD
Availability: InStock

External Watchdog Timer Breakout board for any Micro Controller with reset pin

Designed by Roland W in Thailand

External Watchdog Timer for IoT on MCs 1

External Watchdog Timer for IoT on MCs 2

External Watchdog Timer for IoT on MCs 3

External Watchdog Timer for IoT on MCs 4

External Watchdog Timer for IoT on MCs 5

External Watchdog Timer for IoT on MCs 6







Buy with confidence.

Our Tindie Guarantee protects your purchase from fraud. Learn More

External Watchdog Timer Breakout board for any Micro Controller with reset pin

External Watchdog Timer Breakout Board for any Micro Controller with Reset Pin Every WDT is tested before shipping! If you need other timings or a higher number of boards, please let me know. Watchd…

External Watchdog Timer Breakout Board for any Micro Controller with Reset Pin

Every WDT is tested before shipping! If you need other timings or a higher number of boards, please let me know.

Watchdog Timers are required to watch over MC controlled systems and perform a system reset when the MC gets hung. Use for critical or remote applications, where operator cannot always go and perform a manual reset.

Ideal for IoT applications which require long watch intervals! Apps like, for example Blynk, do require far longer delays than internal WDTs can handle (typically max. 2-8 seconds), while establishing a Wifi and server connection, etc.

Timing till Reset: 35-40 seconds in this setup | Supply Voltage: 5V | Requires: 1 GPIO Pin from Micro Controller to send "Alive Pulse" | Pulse lenght: ~50 ms | Pulse Frequency: at least 1 pulse every 5s under normal operation|

Size 30x28x25mm
