- Features

• Package with output inductor included
• Small size: 3.3mm x 3.3mm x 1.7mm
• Continuous 6A load capability
• High Fsw operating: up to 3MHz
• No external compensation required
• Programmable operation using the I2C serial bus
• Wide input voltage range: 4.5V~16V
• Adjustable output voltage: -AKC2800A: 0.6V~3.0V (6A Max.) -AKC2800B: 3.0V~5.0V (3A Max.) -Enabled input, programmable under-voltage lock-out (UVLO)
• Open-drain power-good indicator
• Built-in protection features: OCP, NOCP, OVP and OTP
• Input voltage, output voltage, and junction temperature reporting
• ROM integrate, 4 times programming available
• 64 I2C slave address and 4 analog offset setting available

- Key Technical

• Die embedded technology:
• Low-Profile: Dimension reduce
  • a. Thin Die exposed in both side
  • b. No wire-bond

• Lower Package Rdson for higher Efficiency

  • a. No need wafer bumping
  • b. Copper pillar interconnection

• COT topology

• Quickly transient response

• Constant current ripple design

• Smaller output ripple

• Programmable operation using the I2C serial bus

• Vout DVS (Dynamic Voltage Scaling) setting
• ADC reporting for Vin, Vout and junction temperature
