The FeatherS3 offers a powerhouse of features in the super popular Feather format offer a huge ecosystem of add-on boards, modules and FeatherWings!

Features & Specifications

• 32Bit Dual Core 240MHz
• RISC-V ultra low power core
• 2.4GHz Wifi - 802.11b/g/n
• Bluetooth 5, BLE + Mesh - 16MB QSPI Flash
• 8MB Extra QSPI PSRAM
• USB-C Connector
• Reverse USB back-feed protection - 2x 700mA 3.3V LDO Regulators
• Ultra low deep sleep current - 2x STEMMA connectors
• Low Power RGB LED
• VBAT voltage check and 5V presence detection
• LiPo Battery Charging
• Power (red), Charge (orange) LEDs
• 21x GPIO broken out
• USB Serial JTAG
• 3D High Gain Antenna
• Compatible with Feather Wings

What's included?

Ships with a set of male headers you can solder on if required.

Ships with CircuitPython pre-installed!

The FeatherS3 ships with the latest version of CircuitPython that supports the ESP32-S3. It also ships with the UF2 bootloader, so you can easily update your FeatherS3 with the latest CircuitPython firmware, whenever you desire.

As newer versions of CircuitPython are released, you are able to update as you require from ciruitpython.org

Code any way you like!

There is also ESP-IDF, MicroPython and Arduino support. Visit the FeatherS3 product page for more details.
