What is MonochromeVGA? MonochromeVGA is a product to enjoy the charm of those monochrome monitors of the time but in the current video systems, and more specifically in your PC monitor. Although it c…
Read More…MonochromeVGA is a product to enjoy the charm of those monochrome monitors of the time but in the current video systems, and more specifically in your PC monitor. Although it could be connected to any TV, monitor or video system that has VGA inputs.
With switch to change color to monochrome and vice versa without disconnecting it.
Now with optional 3D case too, thanks to Agustin Gallego for designing it.
Connecting it directly in a VGA output, it will bridge and convert the RGB signals to a passive equivalent luminance value with a few resistors, then you just have to select the monochrome output by combining the primary colors red, green and blue using the DIP switch.
1: Red
2: Green (75%)
3: Blue
4: Green
Examples:
Green: OFF, OFF, OFF, ON
Amber: ON, ON, OFF, OFF
B&W: ON, OFF, ON, ON
Two types of kit or full Assembled device, now easier to solder thanks to the fact that all footprints are through hole, but thanks to the new design you can also choose a version with the passive SMD alternative components pre-soldered, which will help you with the task of assembling the other components of exclusive through hole technology.
