Keypoints

✏️SYSROX HIGH-PRECISION MAGNETOMETER allowing for 3-axis measurement of magnetic fields enabling precise heading measurement with 0.5° accuracy, ideal for use as a compass. Measurement frequency up to 1000Hz, measurement range of ±8 Gauss with an 18-bit ADC.

✏️NEXT-GENERATION SENSOR (MMC5983MA) HIGH PERFORMANCE replacing older models such as QMC5883L, HMC5883L, LIS3MDL, with unparalleled resolution, precision, and noise levels for this range of sensors.

✏️FULLY CUSTOMIZABLE SOFTWARE for reading, configuring, and calibrating the sensor using SPI bus, compatible with Arduino, perfect for ESP32 or Teensy 4.

✏️MINIATURE DEVELOPMENT BOARD 1cm x 1cm with 2.54mm pin spacing for easy prototyping of robotic applications, drones... Snap-on prototyping pins allow for use on a breadboard or non-permanent mounting on a support board.

✏️ONLINE COMPREHENSIVE DOCUMENTATION enabling easy utilization of the board and extension of the offered functionalities.

Description

⚠️ The offered board only includes the sensors and no microcontroller, which must be added additionally and connected to the board to benefit from the stated functionalities.

The SRX-MAG00-DEV is a high-performance magnetometer that can be used as a base for a heading measurement system.

It includes:

• Magnetometer: Memsic MMC5983MA

The extreme compactness of the board makes it ideal for integration into robotic applications such as drones, rovers...

One of the best consumer grade magnetometer!

The board includes one of the best consumer-grade sensor in terms of noise, resolution, sensitivity... It is therefore a significantly more performing alternative to QMC5883L, HMC5883L, LIS3MDL, perfect for a precise e-compass application

Device functionalities

Utilization of sensor data

• Embedded software 100% compatible with Arduino!
• Full access to raw or processed sensor data, allowing complete integration freedom into any project

Compactness and modularity

The use of clip-on pins allows for easy mounting on a breadboard or semi-permanent mounting on a host board. The pads on the back of the board and its compactness enable integration into any robotic project!

Included:

• Board
• Male and female clip-on pins
• Straight pins

Technical Specs

⚠️ The board is designed to work with SPI communication because of its superior performance and reliability. I2C is supported by the sensor but not by the provided software, pull-up resistors are not included.

• Max Mag Sampling frequency : 1000 Hz
• Max Pressure range : ± 8 Gauss
• ADC resolution : 18 bits
• Magnetic field RMS noise : ±0.4 mGauss
• Heading maximum absolute accuracy : ± 0.5°
• Communication: SPI, I2C
