What is it?

The CFexpress PCIe Hat is an open-source hardware project designed for the Raspberry Pi 5, aimed at enabling direct connection with CFexpress Type B cards. This innovative Hat facilitates high-speed data transfer and storage solutions, making it an essential tool for Raspberry Pi users who require advanced storage capabilities. The project features automated card mounting and unmounting through a CH32V003 MCU for I2C to GPIO control, a QWIIC port standard for easy connectivity, and a QWIIC hub for additional device connections. It can be mounted either on the top or bottom of the Raspberry Pi 5, providing flexible installation options.

Why did you make it?

This project was created to enhance the Raspberry Pi 5 by providing a high-speed storage solution that leverages the advanced capabilities of CFexpress Type B cards. Recognizing the limitations of existing storage options for Raspberry Pi users, the CFexpress PCIe Hat was developed to offer a more robust, efficient, and versatile storage solution. It caters to the needs of hobbyists, educators, and professionals who demand high-speed data processing and storage capabilities for their projects.

What makes it special?

The CFexpress PCIe Hat stands out due to its unique combination of features and flexibility. Its ability to automate the mounting and unmounting process of the NVMe based memory card with a simple eject button provides unmatched convenience. The incorporation of the QWIIC port standard and a QWIIC hub allows for easy and expandable connectivity with other devices without the need for soldering. Moreover, the design's compatibility with both top and bottom mounting on the Raspberry Pi 5, coupled with the open-source nature of the project (facilitated by KiCad), makes it an adaptable and accessible solution for a wide range of users and applications.
